ROBOT WORKER - 自走式拉伸膜缠绕包装机器人
ROBOT WORKER - Self-propelled robot for packaging with stretch film
|
膜架Carriage
|
FRD: 机械式刹车,刹车控制拉伸膜缠紧力。 |
设备参数
Machine Characteristics
|
电池
Batteries : |
2 个 12V 55/60 Ah (C5) lead-acid
|
行走速度 Machine rotation speed
:
|
38-65 m/min |
膜架上升及下降的速度 :
Carriage upward/downward speed |
1-4.6 m/min |
电池充满时的工作能力 :
Number of pallets for battery charge
|
大约 150 个托盘 |
充电的电源
Power supply voltage
: |
230 V +-10% (1Ph) - 50-60 Hz |
动力
Installed power
: |
320 W |
包装物件的极限范围 Characteristics of the product to be wrapped |
最小的物件规格 ( 长 x 宽 ):
Minimum dimensions |
600 x 600 mm |
最大的包装高度Maximum useful height: |
2200 mm |
拉伸膜的规格
Caratteristiche bobina film
|
拉伸膜外径(D)
Max.external diameter
: |
300 mm |
拉伸膜宽度 (h)
Film spool height
: |
500 mm |
拉伸膜厚度
Film thickness
: |
17-35 μm |
拉伸膜内芯直径(d)
Internal diameter
: |
76 mm |
拉伸膜重量
Max. weight
: |
≤ 20 kg |
