ROTOPLAT 3000 HD - 全自动转盘缠绕包装机
ROTOPLAT3000 HD-Automatic turntable with clamp-cut and sealing unit
|
膜架Carriage: |
PFS: 预延伸比例0%-250% 。
Variable Power pre-stretch with force to load electronic control
|
设备参数
Machine Characteristics
|
| 辊筒宽度Conveyor usable width: |
1100 mm |
| 转台速度Turntable rotation speed: |
4-17 rpm |
| 电源Power supply voltage: |
400 Volt 3 Ph + N- 50/60 Hz |
| 功率Installed power: |
3.8 kW |
| 转台高度Conveyor height from the ground: |
500 mm |
包装物件的极限范围 Characteristics of the product to be wrapped |
| 最大的物件规格 ( 长 x 宽 )Minimum dimensions: |
600 x 800 mm |
最大的物件规格 ( 长 x 宽 )Maximum dimensions: |
1000 x 1200 mm |
| 最大的包装高度Maximum useful height: |
2000 mm |
最大的包装高度Maximum
load weight: |
2000kg |
拉伸膜的规格
Caratteristiche bobina film
|
拉伸膜外径(D)
Max.external diameter: |
300 mm |
拉伸膜宽度 (h)
Film spool height: |
500 mm
(optional 750 mm)
|
拉伸膜厚度
Film thickness: |
17-35 μm |
拉伸膜内芯直径(d)
Internal diameter: |
76 mm |
拉伸膜重量
Max. weight: |
≤ 20 kg |
